CB2-M Bafang 36V 250W Gates belt mid drive commuter city electric bike

City riding demands more than just speed; it demands peace of mind. The CB2-M combines the legendary smooth ride of a mid-drive belt system with cutting-edge security technology. Whether parked at a cafe or charging in your apartment, this bike is designed to fit seamlessly—and securely—into your urban lifestyle.

Color: white
Torque
70 Miles
250 W
720 Wh
20+ Mph
7-Speed
300 lb.
Hydraulic
Geometry
A: SEAT TUBE LENGTH (mm)
485
B: SEAT TUBE ANGLE
73°
HEAD TUBE LENGTH (mm)
140
HEAD TUBE ANGLE
71
WHEELBASE(mm)
1170
BOTTOM BRACKET DROP (mm)
65
STACK (mm)
630
REACH (mm)
450
STAND OVER HEIGHT (mm)
400
HANDLEBAR WIDTH (mm)
660
STEM LENGTH (mm)
90
WHEEL SIZE
27.5"
MIN SADDLE HEIGHT(mm)
820
MAX SADDLE HEIGHT(mm)
1060
Specs
Electric system
Motor
BAFANG M420 36V/250W Mid-Drive motor
Controller
BAFANG built-in controller
Battery
36V/20Ah LG/SAMSUNG 21700 720Wh
Charger
36V/3A
Throttle
Optional
Sensor
BAFANG built-in torque sensor
Display
TFT colorful display
Headlight
36V LED light
Taillight
LED with brake light function
Main compents
Frame
Aluminium Alloy 6061 with smooth welding and putty process
Front fork
SR SUNTOUR hydraulic suspension fork with adjustable damping
Tires
27.5"X2.1" tires with reflective line
Chainwheel
GATES CDX 46T
Chain
GATES CDX belt
Derailleur system
SHIMANO Nexus 7 speed Internal gear system
Brake
TEKTRO hydraulic disc brake
Rotors
F:180mm R:180mm
Performance
Max speed
25km/h
Max torque
80N.m
Range
Level 1:  95--100Km Level 5: 50-55km
Charging time
About 5H
Max Load
Recommend no more than 110kg


Description

City riding demands more than just speed; it demands peace of mind. The CB2-M combines the legendary smooth ride of a mid-drive belt system with cutting-edge security technology. Whether parked at a cafe or charging in your apartment, this bike is designed to fit seamlessly—and securely—into your urban lifestyle.


Why the CB2-M is the Ultimate Choice:


1. Ironclad Security: GPS Tracking & Anti-Theft ProtectionStop worrying about bike thieves. The CB2-M features integrated GPS Tracking technology, allowing you to monitor your bike’s location in real-time directly from your smartphone. Park with confidence knowing your ride is smart, connected, and always under your watch.


2. Apartment-Ready: UL-Certified Removable BatteryLiving in an apartment or working in an office tower? We made charging effortless. The high-capacity 48V 15Ah LG Battery slides out smoothly with a turn of a key. Take it inside to charge at your desk or living room, leaving the bike securely locked downstairs. Plus, with UL Certification, you get the highest standard of battery safety for worry-free indoor charging.


3. The "Zero-Maintenance" Ride (Gates Belt + Shimano Nexus)Forget greasy chains and stained pant legs. We’ve equipped this bike with the premium Gates CDX Carbon Drive belt and Shimano Nexus 8-Speed Hub.

           ●  Whisper Quiet: No chain noise, just the sound of the wind.

           ●  Clean: No oil, no grease, no mess. Perfect for professional attire.

           ●  Durable: Lasts 3x longer than chains with virtually zero maintenance.


4. Powerful Precision: Bafang M410 Mid-DriveFlatten the steepest city hills with the Bafang M410 Mid-Drive Motor. Equipped with a sensitive Torque Sensor, it reads your pedaling intent instantly, delivering 80Nm of torque for a ride that feels powerful yet completely natural.


Technical Specifications:


           ●  Smart Tech: Built-in GPS Tracking & App Integration

           ●  Motor: Bafang M410 Mid-Drive (80Nm Torque)

           ●  Transmission: Gates CDX Belt Drive + Shimano Nexus 8-Speed

           ●  Battery: Removable 48V 15Ah LG Cells (UL Certified)

           ●  Brakes: High-Performance Hydraulic Disc Brakes

           ●  Comfort: Suntour NEX Suspension Fork & Adjustable Stem


Ride Smart. Ride Secure.Upgrade to the CB2-M today and experience the freedom of a truly worry-free commute


  • City riding demands more than just speed; it demands peace of mind. The CB2-M combines the legendary smooth ride of a mid-drive belt system with cutting-edge security technology. Whether parked at a cafe or charging in your apartment, this bike is designed to fit seamlessly—and securely—into your urban lifestyle.


    Why the CB2-M is the Ultimate Choice:


    1. Ironclad Security: GPS Tracking & Anti-Theft ProtectionStop worrying about bike thieves. The CB2-M features integrated GPS Tracking technology, allowing you to monitor your bike’s location in real-time directly from your smartphone. Park with confidence knowing your ride is smart, connected, and always under your watch.


    2. Apartment-Ready: UL-Certified Removable BatteryLiving in an apartment or working in an office tower? We made charging effortless. The high-capacity 48V 15Ah LG Battery slides out smoothly with a turn of a key. Take it inside to charge at your desk or living room, leaving the bike securely locked downstairs. Plus, with UL Certification, you get the highest standard of battery safety for worry-free indoor charging.


    3. The "Zero-Maintenance" Ride (Gates Belt + Shimano Nexus)Forget greasy chains and stained pant legs. We’ve equipped this bike with the premium Gates CDX Carbon Drive belt and Shimano Nexus 8-Speed Hub.

               ●  Whisper Quiet: No chain noise, just the sound of the wind.

               ●  Clean: No oil, no grease, no mess. Perfect for professional attire.

               ●  Durable: Lasts 3x longer than chains with virtually zero maintenance.


    4. Powerful Precision: Bafang M410 Mid-DriveFlatten the steepest city hills with the Bafang M410 Mid-Drive Motor. Equipped with a sensitive Torque Sensor, it reads your pedaling intent instantly, delivering 80Nm of torque for a ride that feels powerful yet completely natural.


    Technical Specifications:


               ●  Smart Tech: Built-in GPS Tracking & App Integration

               ●  Motor: Bafang M410 Mid-Drive (80Nm Torque)

               ●  Transmission: Gates CDX Belt Drive + Shimano Nexus 8-Speed

               ●  Battery: Removable 48V 15Ah LG Cells (UL Certified)

               ●  Brakes: High-Performance Hydraulic Disc Brakes

               ●  Comfort: Suntour NEX Suspension Fork & Adjustable Stem


    Ride Smart. Ride Secure.Upgrade to the CB2-M today and experience the freedom of a truly worry-free commute
